Spring

The Heartway Spring is a manual wheelchair with a lightweight aluminum frame. The Spring uses a Tilt N Space seat that operates manually. The Tilt N Space seat reclines up to 30 degrees.

The Spring Has a weight capacity of 300 lbs and weighs only 84 lbs. The Spring features 24″ quick-release drive wheels. The ergonomic seat is available in 16″, 18″, and 22″ widths.

MAX SPEED
N/A
MPH

Load Capacity
300
LBS

Battery
N/A

Range
N/A
Miles

SPECS

Overall Length 45″ in / 115 cm
Overall Width 26″ in / 66 cm  // 27″ in / 70 cm

// 31″ in / 80 cm

Overall Height at Backrest 50″ in / 122 cm  // 56″ / 142 cm
Overall Height – at Minimum Tiller Height N/A
Legroom – Floorboard Length x Width 15.7-19.7″ in /40-50 cm
Deck Height – Floorboard to Floor 4-7.9″ in /10-20 cm
Turning Radius 39.4″ in /100 cm
Weight with Std. 84 lbs / 38 kg
Seat Type Rehab Seat
Seat – Width & Depth & Height 16″ in / 40 cm // 18″ in / 45 cm

// 22″ in / 55 cm

Seat – Cushion Thickness 4″ in /10 cm
Seat Height – Cushion to Deck 15.7″ in /40 cm
Seat Height – Cushion to Floor 21.7″ in /55 cm
Tire Type Solid Tires
Rim Type Rear Industrial Plastic
Rim Type Front Industrial Plastic
OEM Spec Rear N/A
Outside Diameter Rear 24″ in /61 cm
Tire Width Rear 1-3/8″ in /3.5 cm
OEM Spec Front N/A
Outside Diameter Front 8″ in /20 cm
Tire Width Front 2″ in /5 cm
Climbing Angle – Maximum Recommended 6 degree
Load Capacity 300 lbs / 135 kgs
Colors Silver
(*) SPECIFICATION PERFORMANCE IS DETERMINED IN THE LABORATORY SETTING BASED ON IDEAL CONDITIONS (MINIMAL FRICTION, NO WIND AND CONTROLLED TEMPERATURE AND PRESSURE WITH AN AVERAGE STANDARD WEIGHT). ACTUAL PERFORMANCE WILL BE DIFFERENT THAN RESULTS OBTAINED DURING LABORATORY TESTING.
